Qi Wireless charger

Function
matching with Qi-compliant power bank or power receiver, the wireless charging pad can   wireless charge for any Qi-enabled devices.

Support Devices
allow to charge for any of Qi compliant devices: such as iPhone 4S/4, Blackberry, HTC, Samsung Galaxy S3 as well as gaming cosole like 3DS, PS3 controller, XBOX 360 controller and etc.

Features

Power conversion efficiency up to 78 percent, can provide up to DC 5V/1A transmission capacity, the charging pad enables powering or charging for any other DC 5V devices like iPhone 4, iPad, Blackberry and etc.

It adopts intelligent identification system while its transmitter and receiver unit adopts UART (Universal asynchronous receiver / transmitter) encrypted transmission control signal which is stipulated by WPC.

Magnetic alignment between wireless charging pad and receiver (jacket) to guide the user for correct placement of their portable devices.

 LED display working status:
1, LED OFF is Power disconnected  (no product place on charging area);
2, Blue LED is charging and working normally;

3, Red LED flashing at 1Hz speed: transmit power adjusting;

4, Red Light always ON is abnormal working.

Specially designed power adaptor with AC100-240V / 50-60HZ Power, suitable for all countries and regions user.

Specification
Dimensions: 110x 155x  20mm
Net weight:180g, Gross weight: 300g
Colour: White

Standard Content

TS01 Qi Wireless Charger

Power Adaptor
User manual
